Nuron

SF 6H-22 Cordless hammer drill driver

SF 6H-22 3rd generation Nuron cordless hammer drill driver with B22-85 battery
SF 6H-22 3rd generation Nuron cordless hammer drill driver with B22-85 battery and spade bit
SF 6H-22 3rd generation Nuron cordless hammer drill driver with B22-85 battery and HSS drill bit
SF 6H-22 3rd generation Nuron cordless hammer drill driver with B22-85 battery and masonry drill bit

Power-class hammer drill driver with Active Torque Control and advanced ergonomics for universal drilling and driving in wood, metal and masonry (Nuron battery platform)

  • Maximum torque (Soft / Hard Joint): 65 Nm (soft joint), 85 Nm (hard joint)
  • No load RPM: gear 1: 490 rpm; gear 2: 2000 rpm
  • Chuck clamping range: 2 - 13 mm

Customers also searched for cordless hammer drill, hammer drill driver, cordless drill, cordless drill driver or SF 6H-22.

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
From BD 428.20

Technical Data

Maximum torque (Soft / Hard Joint)
65 Nm (soft joint), 85 Nm (hard joint)
No load RPM
gear 1: 490 rpm; gear 2: 2000 rpm
Chuck clamping range
2 - 13 mm
Number of gears
2
Torque increments
15
Dimensions (LxWxH)
208 x 68 x 215 mm
Tool body weight
1.677 kg
A-weighted emission sound pressure level
98 dB (A) 1
Rated voltage
21.6 V
Triaxial vibration value for drilling into metal (ah,D)
1.1 m/s² 2
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see Operating Instruction for more details)

Documents

pdf Material safety datasheet LI-ION-BATTERIES >100Wh (AR) [ 324.1 KB ]
pdf Material safety datasheet LI-ION-BATTERIES >100Wh (EN) [ 213.8 KB ]

Features & Applications

Features

  • High-speed, high-torque cordless hammer drill driver built to help you save time with every hole you drill or screw you drive, including in masonry
  • Uncompromised cordless performance – drill and drive more per charge at consistently high speed thanks to Nuron batteries and the brushless motor
  • Built to last – full metal chuck, brushless motor, rubber bumpers and optimised cooling to better withstand intense use under tough jobsite conditions
  • Advanced safety features – Active Torque Control (ATC) helps to prevent the tool body from uncontrolled spinning if the drill bit sticks, and an LED work light in the base provides a clear view of your work area
  • On the Nuron battery platform – cordless tools without compromise thanks to longer-lasting batteries, energy-saving drill bits and a range of services to keep you more productive, today and tomorrow

Applications

  • Hammer drilling in brick, masonry and aerated concrete (max. diameter 14 mm)
  • Cutting recesses and through-holes with hole saws (max. diameter 127 mm)
  • Drilling with auger and spade bits in wood (max. diameter 32 mm)
  • Fast driving of self-drilling screws in metal (max. diameter 6.3 mm)
  • Fast drilling with high torque in metal (max. diameter 13 mm)

For approval or certificate information, please see individual items.
