CALCULATING INSTALLATION SYSTEM SUPPORTS
PROFIS design software for modular support systems
SIMPLER DESIGNER MODULES
Channel design module
- Calculate all installation channels or brackets
- Simple click and input functionality
- Find the most economical channel or bracket from our Hilti portfolio
Template design module
- Pre-designed template database for all channel systems
- Simple click and input functionality
- Get a static report on how to use our Hilti connectors and channels
Fixed-point module
- Calculate expansion solutions: bending arm, U-bend, axial expansion joint
- Find the most economical Hilti fixed-point solution
- Get a bill of material including installation instructions
EXPERT DESIGNER MODULES
3D design module
- 3D static system modelling and analysis
- Customized design
- Get a static report on how to use our Hilti connectors and channels
Seismic template design
- Pre-designed template database for seismic applications including how to use seismic installation parts
- Includes calculation and load cases based on seismic codes
EXTENSIVE BIM/CAD LIBRARY
BIM/CAD Library
- Use our extensive library of BIM/CAD images
- Export BIM/CAD images easily to other design platforms
